SPECIFICATIONS
| Nominal diameter |
8” in/ 203mm |
| Nominal impedance | 8Ω |
|
Max power |
1800W |
|
RMS Power |
900W |
|
Sensivity (1W/1m) |
95 dB |
|
Frequency Range |
145-10.5KHz |
|
Voice coil diameter |
3.5” in / 88.5mm |
|
Winding material |
Inside-outside CCAW |
|
Magnet |
61 OZ |
|
Magnet material |
Ferrite |
MOUNTING/SHIPPING INFORMATION
|
Overall diameter |
8”/ 203 |
In/mm |
|
Bolt circle diameter |
7.9” / 201 |
In/mm |
|
Baffle cutout diameter |
7.5” / 191 |
In/mm |
|
Mounting Depth |
3.6” / 91.44 |
In/mm |
|
Net Weight |
5.60 / 12.3 |
Kg/Lb |
|
Shipping Weight |
5.95 / 13 |
Kg/Lb |
|
Shipping Box |
23x23x13 |
cm |
